RG-ES100 Series Metal Case Unmanaged Switches
Reyee Switch RG-ES105GD. Ruijie Seri Real-easy RG-ES105D / RG-ES108D / RG-ES105GD / RG-ES108GD adalah Switch akses tidak terkelola yang hemat biaya dengan casing logam yang dirancang untuk UKM. Seri RG-ES100 mendukung plug-and-play tanpa memerlukan konfigurasi apa pun, yang dapat memenuhi persyaratan berbagai skenario seperti jaringan kabel, nirkabel, dan pengawasan.
Plug and Play
Seri RG-ES100 mendukung port adaptif mandiri dan fitur plug-and-play dengan konfigurasi nol.
Metal Casing
Seluruh casing terbuat dari logam yang memberikan pembuangan panas lebih baik.
Easy to Install
Ukurannya yang ringkas memungkinkan pemasangan yang mudah di kotak ELV di rumah atau kotak sambungan pengawasan tahan air, karena hanya membutuhkan sedikit ruang.
Enterprise-grade Quality
Kabel jaringan 8-inti berkualitas tinggi dan komponen kelas perusahaan memastikan tidak ada paket yang hilang atau tertinggal untuk transmisi data.
| Model | ES105D | ES108D | ES105GD | ES108GD |
| Model | ES105D | ES108D | ES105GD | ES108GD |
| Ports | 5 10/100Mbps RJ45 ports | 8 10/100Mbps RJ45 ports | 5 10/100/1000Mbps RJ45 ports | 8 10/100/1000Mbps RJ45 ports |
|
Maximum port forwarding rate |
100Mbps | 100Mbps | 1000Mbps | 1000Mbps |
| Auto–MDI/MDIX | Support | Support | Support | Support |
| MAC address | 1K | 2K | 2K | 8K |
| Backplane bandwidth | 1Gbps | 1.6Gbps | 10Gbps | 16Gbps |
| Maximum packet forwarding rate | 744Kpps | 1.19Mpps | 7.44Mpps | 11.9Mpps |
| LED indicator | Link/Act status LED indicator for each port,
Power indicator |
Link/Act status LED indicator for each port,
Power indicator |
Link/Act status LED indicator for each port,
Power indicator |
Link/Act status LED indicator for each port,
Power indicator |
| Dimensions | 119mm*62mm*24mm | 160mm*75mm*24mm | 119mm*62mm*24mm | 160mm*75mm*24mm |
| Power input / output | External 5VDC 1.0A | External 5VDC 1.0A | External 5VDC 1.0A | External 5VDC 1.0A |
| Maximum power consumption | ≤5W | ≤5W | ≤5W | ≤5W |
| Temperature | Operating temperature:
0 ℃ ~ 40 ℃ Storage temperature: -40 ℃ ~ 70 ℃ |
Operating temperature:
0 ℃ ~ 40 ℃ Storage temperature: -40 ℃ ~ 70 ℃ |
Operating temperature:
0 ℃ ~ 40 ℃ Storage temperature: -40 ℃ ~ 70 ℃ |
Operating temperature:
0 ℃ ~ 40 ℃ Storage temperature: -40 ℃ ~ 70 ℃ |
| Humidity |
Operating humidity: 10% ~ 90% non-condensing Storage humidity: 5% ~ 90% non-condensing |
Operating humidity: 10% ~ 90% non-condensing Storage humidity: 5% ~ 90% non-condensing |
Operating humidity: 10% ~ 90% non-condensing Storage humidity: 5% ~ 90% non-condensing |
Operating humidity: 10% ~ 90% non-condensing Storage humidity: 5% ~ 90% non-condensing |
| Model | Description |
|
RG-ES105D |
5 10/100M RJ45 ports, metal casing, external 5VDC 1.0A power adapter |
|
RG-ES105GD |
5 10/100/1000M RJ45 ports, metal casing, external 5VDC 1.0A power adapter |
|
RG-ES108D |
8 10/100M RJ45 ports, metal casing, external 5VDC 1.0A power adapter |
|
RG-ES108GD |
8 10/100/1000M RJ45 ports, metal casing, external 5VDC 1.0A power adapter |
